The high-torque PK/PKP series stepper motor offers balanced performance enhanced by high torque, low vibration and low noise.
Item # |
Frame Size |
Basic Step Angle |
Speed-Torque Characteristics |
Holding Torque |
Current per Phase |
Shaft/Gear Type |
Gear Ratio (X:1) |
Encoder Output |
Electromagnetic Brake |
Shaft |
Web Price |
|---|---|---|---|---|---|---|---|---|---|---|---|
| PK566NAW-R27L | - 2.36 in | - 0.72° |
 Speed-Torque Characteristics |
- 117 oz-in | - 1.40 A/phase | - Round Shaft (No Gearhead) | - | - 500 P/R Differential, 3-Channel | - Not Equipped | - Single | - $169.00 |
| PK569NAW-R27L | - 2.36 in | - 0.72° |
 Speed-Torque Characteristics |
- 230 oz-in | - 1.40 A/phase | - Round Shaft (No Gearhead) | - | - 500 P/R Differential, 3-Channel | - Not Equipped | - Single | - $197.00 |
| PK564PMA-R28L | - 2.36 in | - 0.36° |
 Speed-Torque Characteristics |
- 110 oz-in | - 1.40 A/phase | - Round Shaft (No Gearhead) | - | - 1000 P/R Differential, 3-Channel | - Not Equipped | - Single | - $181.00 |
| PK566PMA-R28L | - 2.36 in | - 0.36° |
 Speed-Torque Characteristics |
- 184 oz-in | - 1.40 A/phase | - Round Shaft (No Gearhead) | - | - 1000 P/R Differential, 3-Channel | - Not Equipped | - Single | - $188.00 |
| PK569PMA-R28L | - 2.36 in | - 0.36° |
 Speed-Torque Characteristics |
- 320 oz-in | - 1.40 A/phase | - Round Shaft (No Gearhead) | - | - 1000 P/R Differential, 3-Channel | - Not Equipped | - Single | - $248.00 |
| PK564AW-PS25 | - 2.36 in | - 0.72° |
 Speed-Torque Characteristics |
- 1130 oz-in | - 1.40 A/phase | - Planetary Gear | - 25 :1 | - | - Not Equipped | - Single | - $550.00 |
| PK564AW-PS36 | - 2.36 in | - 0.72° |
 Speed-Torque Characteristics |
- 1130 oz-in | - 1.40 A/phase | - Planetary Gear | - 36 :1 | - | - Not Equipped | - Single | - $550.00 |
| PK564AW-PS50 | - 2.36 in | - 0.72° |
 Speed-Torque Characteristics |
- 1130 oz-in | - 1.40 A/phase | - Planetary Gear | - 50 :1 | - | - Not Equipped | - Single | - $550.00 |
| PK564BW-PS25 | - 2.36 in | - 0.72° |
Speed-Torque Characteristics |
- 1130 oz-in | - 1.40 A/phase | - Planetary Gear | - 25 :1 | - | - Not Equipped | - Double | - $554.00 |
| PK564BW-PS36 | - 2.36 in | - 0.72° |
Speed-Torque Characteristics |
- 1130 oz-in | - 1.40 A/phase | - Planetary Gear | - 36 :1 | - | - Not Equipped | - Double | - $554.00 |
| PK564BW-PS50 | - 2.36 in | - 0.72° |
Speed-Torque Characteristics |
- 1130 oz-in | - 1.40 A/phase | - Planetary Gear | - 50 :1 | - | - Not Equipped | - Double | - $554.00 |
| PK566AW-PS10 | - 2.36 in | - 0.72° |
 Speed-Torque Characteristics |
- 710 oz-in | - 1.40 A/phase | - Planetary Gear | - 10 :1 | - | - Not Equipped | - Single | - $472.00 |
| PK566AW-PS5 | - 2.36 in | - 0.72° |
 Speed-Torque Characteristics |
- 490 oz-in | - 1.40 A/phase | - Planetary Gear | - 5 :1 | - | - Not Equipped | - Single | - $472.00 |
| PK566AW-PS7 | - 2.36 in | - 0.72° |
 Speed-Torque Characteristics |
- 560 oz-in | - 1.40 A/phase | - Planetary Gear | - 7.2 :1 | - | - Not Equipped | - Single | - $472.00 |
| PK566BW-PS10 | - 2.36 in | - 0.72° |
Speed-Torque Characteristics |
- 710 oz-in | - 1.40 A/phase | - Planetary Gear | - 10 :1 | - | - Not Equipped | - Double | - $476.00 |
| PK566BW-PS5 | - 2.36 in | - 0.72° |
Speed-Torque Characteristics |
- 490 oz-in | - 1.40 A/phase | - Planetary Gear | - 5 :1 | - | - Not Equipped | - Double | - $476.00 |
| PK566BW-PS7 | - 2.36 in | - 0.72° |
Speed-Torque Characteristics |
- 710 oz-in | - 1.40 A/phase | - Planetary Gear | - 7.2 :1 | - | - Not Equipped | - Double | - $476.00 |
| PK564AWR27LH50 | - 2.36 in | - 0.72° |
 Speed-Torque Characteristics |
- 768 oz-in | - 1.40 A/phase | - Harmonic Gear | - 50 :1 | - 500 P/R Differential, 3-Channel | - Not Equipped | - Single | - $1,165.00 |
| PK564AWR27LH100 | - 2.36 in | - 0.72° |
 Speed-Torque Characteristics |
- 1120 oz-in | - 1.40 A/phase | - Harmonic Gear | - 100 :1 | - 500 P/R Differential, 3-Channel | - Not Equipped | - Single | - $1,165.00 |
| PK564AWR27LPS25 | - 2.36 in | - 0.72° |
Speed-Torque Characteristics |
- 1130 oz-in | - 1.40 A/phase | - Planetary Gear | - 25 :1 | - 500 P/R Differential, 3-Channel | - Not Equipped | - Single | - $636.00 |
| PK564AWR27LPS36 | - 2.36 in | - 0.72° |
Speed-Torque Characteristics |
- 1130 oz-in | - 1.40 A/phase | - Planetary Gear | - 36 :1 | - 500 P/R Differential, 3-Channel | - Not Equipped | - Single | - $636.00 |
| PK564AWR27LPS50 | - 2.36 in | - 0.72° |
Speed-Torque Characteristics |
- 1130 oz-in | - 1.40 A/phase | - Planetary Gear | - 50 :1 | - 500 P/R Differential, 3-Channel | - Not Equipped | - Single | - $636.00 |
| PK564AWR27LT3.6 | - 2.36 in | - 0.72° |
 Speed-Torque Characteristics |
- 176 oz-in | - 1.40 A/phase | - Taper Hobbed Gear | - 3.6 :1 | - 500 P/R Differential, 3-Channel | - Not Equipped | - Single | - $324.00 |
| PK564AWR27LT7.2 | - 2.36 in | - 0.72° |
 Speed-Torque Characteristics |
- 352 oz-in | - 1.40 A/phase | - Taper Hobbed Gear | - 7.2 :1 | - 500 P/R Differential, 3-Channel | - Not Equipped | - Single | - $324.00 |
| PK564AWR27LT10 | - 2.36 in | - 0.72° |
 Speed-Torque Characteristics |
- 416 oz-in | - 1.40 A/phase | - Taper Hobbed Gear | - 10 :1 | - 500 P/R Differential, 3-Channel | - Not Equipped | - Single | - $338.00 |
