Item # VHI315A2-GVU, Induction Motor On Oriental Motor 2

Supporte: 01-800-681-5309

El contenido a continuación está en inglés

Request Information

This product is scheduled to be discontinued, please contact your local sales office for more information.

Compatible Motors (sold separately)

Unit of Measure

Product Line	- Oriental Motor ®
Motor Type	- Induction
Frame Size	- 2.76 in70 mm
Output Power	- 15 W (1/50 HP)
Voltage (VAC)	- Single-Phase 110/115 VAC
Frequency (Hz)	- 60
Current	- 0.33 A [110 VAC] 0.34 A [115 VAC]
Shaft/Gear Type	- Pinion Shaft (Gearhead required - sold separately)
Type	- Lead Wire
RoHS Compliant	- Yes
Safety Standards	- UL CSA CCC EN CE
CE Marking	- Low Voltage Directives
Insulation Resistance	- 100 M Ω or more when 500 VDC is applied between the windings and the frame after rated motor operation under normal ambient temperature and humidity.
Dielectric Strength	- Sufficient to withstand 1.5 kV at 50 Hz or 60 Hz applied between the windings and the frame for 1 minute after rated motor operation under normal ambient temperature and humidity.
Temperature Rise	- Temperature rise of windings are 176°F (80°C) or less measured by the resistance change method after rated motor operation with connection to gearhead.
Insulation Class	- Class B (266°F [130°C])
Overheat Protection	- Built-in thermal protector (Automatic return type). Operating temperature, open: 266°F ± 9°F (130°C ± 5°C) close: 179.6°F ± 27°F (82°C ± 15°C)
Ambient Temperature Range	- 14°F ~ 104°F (-10°C ~ 40°C) (nonfreezing)
Ambient Humidity	- 85% maximum (noncondensing)
Degree of Protection	- IP20
